| Displacement cc/rev: | 6 - 47.6 |
| Gear Widths: | 1/4" - 2" |
| Max PSI / BAR: | 2000 / 138 |
| RPM: | 400 - 2000 |
P1500 Series
P1500 Series
The P1500 series is a small displacement, roller bearing gear pump from Permco.
Free Technical Downloads
Permco 1500 Data Sheet Permco 1500 Codebook
Product Overview
The Permco P1500 is a small frame sized, hydraulic roller bearing gear pump.
The 1500 series allows the option for a smaller displacement in a roller bearing unit.
A high pressure shaft bushing is also available if required.
The P1500 series gear pump is built from cast iron ensuring a strong and long lasting product, which can stand the most robust applications. Single & multiple units are available as per your requirements.
The pressure loaded wear plates of the pump, provides you with a high efficient product.
A wide range of configurable mounting, shaft and porting options are available to suit your unique requirements.
Compatible with Mineral Oil, Water Glycol, Invert Emulsion & Fire Resistant fluids.
Spare parts available from stock, such as seal kits, flanges, shafts and individual pump sections enabling a fast turnaround for you if required.
Our Service to you
We machine, build from stock and test the P1500 gear pump on site, to ensure the highest quality and a workable product is delivered to you. The P1500 gear pump also comes with a 12 month warranty.
We aim to always supply the best competitive price for this product. Your welcome to provide us with a guide price to see if we can price match it.
In the event your product breaks down in the first 12 months, please contact sales on: sales@hydra-perm.co.uk or +44(0) 113 236 1367 so we can discuss the best option for you.
In the event of an emergency or you have a machine breakdown; we can supply this product to you with a 24 / 48 turnaround.
Common Applications
Customers of ours have used this gear pump in applications such as:
- Turbines
- Marine Applications
But can be applied to a wide range of mobile machinery within a variety of industries.
ATEX Information
The P1500 can be supplied as an ATEX gear pump if required. ATEX Group I & II certification is required, if the product will be used in potentially explosive atmospheres.
ATEX gear pumps are ideally suited for applications in the mining, oil & gas industry.
Mounting, Drive Shaft, Porting Options
Product Coding Example
Pump Performance
Recommended Operating Conditions
- Fluid viscosity, normal operating conditions 9 – 220 cst.
- Fluid temperature should not exceed 82 deg C for mineral oil or 57 deg. C for water glycol.
- Fluid cleanliness, 10 micron filter with Beta 200 rating is recommended.
- Inlet pressure; for best operation with mineral oil, pressure should not exceed minus 0.237 BAR (7 in HG) or with water glycol, minus 0.101 BAR (3 in HG)
Weights & Dimensions
